Detalles del producto:
Datos técnicos:
| Rated Voltage ,kV | 42339 | 42339 | 24/27 | 24/27 | 36 | 36 |
| Rated Current, A | 100 | 200 | 100 | 200 | 100 | 200 |
| Rated Breaking current, A | 8 | 8 | 8 | 8 | 8 | 8 |
| BIL, kV | 110 | 110 | 150 | 150 | 200 | 200 |
| Power frequency withstand voltage (dry 1min), kV | 55 | 55 | 70 | 70 | 95 | 95 |
| Leakage Distance, mm | 440 | 440 | 600 | 600 | 790 | 790 |
| Height H, mm | 405 | 405 | 500 | 500 | 600 | 600 |
| Tube length L, mm | 310 | 310 | 380 | 380 | 480 | 480 |
| Weight, kg | 5.6 | 5 | 6.6 | 6.6 | 8.6 | 8.8 |
